1965 Beechcraft S35 Bonanza N6130V - $199,000
Fresh IO-550 - New Interior - New Panel - Mint
Summary
We purchased this beautiful S35 Bonanza for it's corporate pilot owner six years ago in 2020... and the love affair began, Since that time, the aircraft has undergone a continuing metamorphosis with major upgrades - new interior, new panel, airframe upgrades, and an IO-550 reman engine. The result is a nearly autonomous 182 knot speedster with a solid 6 hour range, allowing the new owner to fly almost anywhere... FAST! Aircraft logbooks are complete but pending.
Click On The Photos Below to Enlarge The Slideshow
Airframe
- Serial Number D-7797
- AFTT 6,626.2
- Based KMMH
- Seats Four(4) Seats
- Damage History Prior Gear Up in 1977
- Hangared Always Since New
- Complete Original Logs Yes
- Annual Due 08/31/26
- IFR Checks Due Due Now
- ELT Battery Due Due Now
- W&B 3,500 GW, 2,372.4 EW, 80.82" CG, 1,027.6 Useful Load
Avionics
- Audio Panel PSE PMA450BC Bluetooth Audio
- Autopilot Garmin GFC 500 Digital A/P
- Chronograph Davtron MB800 Yoke Chronograph
- Digital Instrument Garmin GI 275
- Engine Management Garmin GI 275
- Flight Director Garmin GI 275
- GPS #1 Garmin GTN 650xi IFR WAAS GPS/Nav/Comm
- GPS #2 Garmin GNS 430W IFR WAAS GPS/Nav/Comm
- HSI Garmin GI 275
- Intercom PSE PMA 450B Bluetooth Audio
- Transponder Garmin GTX345 ADS-B I/O
- Accessories Avionics Master
Standard Model Data - S35
- Dimensions Height: 7'7", Wing Span: 33'6", Length: 25' 1", Cabin Height: 4' 2", Cabin Width: 3' 6", Cabin Length: 8/6, Cabin Door Width: 37", Cabin Door Height: 36", Baggage Door Dimensions: 22.5 x 18.5. Main Baggage Space: 16.5 cu ft
- Operating Weights Gross Weight: 3,300 lbs, Empty Weight: 1,950 lbs, Useful Load: 1,350 lbs Standard Useable Fuel Capacity: 44 Gals, Payload w/ Standard Full Fuel: 906 lbs, Extended Useable Fuel Capacity 74 Gals, Payload w/ Full Useable Extended Fuel: 726 lbs, Main Baggage Capacity: 270,
- Speeds Max Speed Vne: 195 KIAS, Max Structural Cruise Vno: 165 KIAS, Maneuvering Speed Va: 132 KIAS, Flaps Approach / Max Extension Speeds Vfe: 113 KIAS, Landing Gear Extension Vlg: 143 KIAS, Stall Speed Vs: 63 KIAS, Stall Speed (Dirty) Vso: 54 KIAS, Best Rate Of Climb Vy: 96 KIAS, Best Angle Of Climb Vx: 76 KIAS, Cruise Climb Speed: 107 KIAS, Best Glide Speed: 105 KIAS.
- Performance T/O Ground Roll: 880 ft, T/O Distance Over 50 Ft Obstacle: 1,225 ft, Landing Distance: 625 ft, Landing Distance Over 50 ft Obstacle: 1,150 ft, Initial Rate Of Climb: 1,200 fpm, Absolute Ceiling: 18,300 ft, Service Ceiling: 18,300 ft, Minimum Range: 690 nm,
Engine & Propeller
- Engine Continental IO-550-BB, 300 HP, 1,900 TBO, 12 SFRM in 2025. Compressions XX/XX/XX/XX/XX/XX over 80, Serviced w/ AeroShell 15W50.
- Propeller Hartzell Model HPC-C3YR-1RF, 3-Blade Propeller, Hub S/N XXXXXX, XXXX TT, 12 SPOH
Airframe Enhancements / Modifications
- Exterior Paint White, Gold and Insignia Blue
- Interior Paint New Complete AirTex Leather Interior including Headliner
- Other 3 Point Strobes, Static Wicks, Shoulder Harnesses, Polished Spinner, BDS Baffle Kit, D'Shannon Engine Compartment Floor Boards, Aileron/Flap Gap Seals, Whelen Upper LED Beacon, Whelen Belly LED Beacon, Copilot Vent Window, Walker Air Skeg, 20 Gallon Tip Tanks (114 Gal Usable), 200 Lb GWI, NuLite Instrument Backlights, New Klixon Circuit Breakers, Large Baggage Door, Colored Control Knobs, Cabin Cover, SideWinder Tub, Ground Power Unit, and Custom Cowl Plugs.
Recent Maintenance
- Coming Soon
Standard Model Data - S35
- Specifications Wing Area: 181 sq ft, Wing Loading: 18.23 lbs/sf, Power Loading: 11.58 hp/sq ft, Standard Fuel (Total): 50 Gal, Standard Fuel (Useable): 44 Gal, Extended Fuel: 80 Gal, Extended Fuel (Useable): 74 Gal, Oil Capacity (Each Engine): 12 quarts.
Meriden Markham Municipal Airport - KMMK
Meriden, CT USA
