1981 Beechcraft A36 Bonanza N81HB - Price Pending
PowerMaster IO-550 - NDH - Glass - Quality Maintenance
Summary
This beautiful, lovingly maintained, 1981 Beechcraft IO-550 powered A36 Bonanza is the perfect airplane for family or business travel. Starting with the mid-life Bill Cunningham (PowerMaster Engines) custom IO-550 engine, Garmin glass, and its I/O ADS-B functionality, the airplane is fully equipped and sure to serve the most discerning owner-pilot well. If you're looking for an aircraft that exemplifies pride of ownership, N81HB is the perfect business airplane equally suited to create memories with family and friends and is sure to bring you years of safe and reliable transportation.
Click On The Photos Below to Enlarge The Slideshow
Airframe
- Serial Number E-1902
- AFTT 5,518.5
- Based KICT
- Seats Six (6) Seats
- Damage History No Damage History
- Hangared Always Since New
- Complete Original Logs Yes
- Annual Due 07/31/27
- IFR Checks Due 06/30/27
- ELT Battery Due 03/31/27
- W&B GW 3,700 lbs, EW 2,279.18, Useful Load 1,426.82, CG 77.76
Avionics
- ADS-B Garmin GDL 88 I/O
- Audio Panel Garmin GMA 35 Remote
- Autopilot Bendix King KFC 200 A/P
- Chronometer Davtron M800B
- Engine Management JPI EDM 930
- EFIS Garmin G500 PFD / MFD
- EFIS RC Allen RCA2610-3 (3 Inch) Standby AI
- Fuel Flow JPI EDM 930
- IFE Avionics Innovations 14001-00 AI-CD CD Player FM Tuner
- GPS #1 Garmin GTN750 IFR WAAS GPS/Nav/Comm
- GPS #2 Garmin GTN650 IFR WAAS GPS/Nav/Comm
- Intercom Avionics Innovations 14001-00 AI-CD
- Transponder Garmin GTX 33 Remote
- Accessories Avionics Master, 6 Place Intercom
Standard Model Data - A36 Bonanza
- Dimensions Height: 8'7", Wing Span: 33'6", Length: 27'6", Cabin Height: 4'2", Cabin Width: 3'6", Cabin Length: 10'11", Cabin Door Width: 37", Cabin Door Height: 36", Baggage Door Dimensions: 45" x 35". Total Baggage Space: 37 cu ft.
- Operating Weights Gross Weight: 3,600 lbs, Empty Weight: 1,620 lbs, Useful Load: 1,980 lbs, Standard Useable Fuel Capacity: 74 Gals, Payload w/ Standard Full Fuel: 1,536 lbs, Extended Useable Fuel Capacity 114 Gals, Payload w/ Full Useable Extended Fuel: 1,356 lbs, Total Baggage Capacity: 400, Aft Baggage Capacity: 70 lbs
- Speeds Max Speed Vne: 204 KIAS, Max Structural Cruise Vno: 166 KIAS, Maneuvering Speed Va: 140 KIAS, Flaps Approach / Max Extension Speeds Vfe: 123 KIAS, Landing Gear Extension Vlg: 153 KIAS, Stall Speed Vs: 62 KIAS, Stall Speed (Dirty) Vso: 56 KIAS, Best Rate Of Climb Vy: 96 KIAS, Best Angle Of Climb Vx: 78 KIAS, Cruise Climb Speed: 109 KIAS, Best Glide Speed: 110 KIAS
- Performance T/O Ground Roll: 1,140 ft, T/O Distance Over 50 Ft Obstacle: 2,040 ft, Landing Distance: 840 ft, Landing Distance Over 50 ft Obstacle: 1,450 ft, Initial Rate Of Climb: 1,030 fpm, Absolute Ceiling: 16,600 ft, Service Ceiling: 16,600 ft, Minimum Range: 861 nm
Engine & Propeller
- Engine Continental IO-550-B S/N 684850, 300 HP, 1,700 TBO, 743.7 SMOH By PowerMaster Aircraft Engines in May 2012 to new factory limits. Cylinder compressions: 1-75 / 2-74 / 3-75 / 4-74 / 5-75 / 6-74, Serviced w/ Phillips 20W-50 XC engine oil.
- Propeller McCauley Model 3A32C406-C, 3-Blade Propeller, Hub S/N 991762, 2,118.09 TT, 746.0 SPOH in September 2012.
Airframe Enhancements / Modifications
- Exterior Paint Refinished in 1993 with Dupont Imron base white 817, and Gold 44469 and Black 99U Imron polyurethane trim colors. Wing leading edges painted with Sherwin Williams Black Velvet #10684. Rated 8 of 10.
- Interior Medium tan leather rated 8 of 10.
- Other LED Beacon, LED Landing & Taxi Lights, Tinted Glass in 2022, 100 Amp Alternator, 3 Point Strobes, 3 Blade Prop, Polished Spinner, Reiff Preheater, Gami Injectors, D'Shannon Baffles, GPSS, Static Wicks,
Standard Model Data - A36 Bonanza
- Specifications Wing Area: 181 sq ft, Wing Loading: 19.9 lbs/sf, Power Loading: 12.6 hp/sq ft, Standard Fuel (Total): 80 Gal, Standard Fuel (Useable): 74 Gal, Extended Fuel: 120 Gal, Extended Fuel (Useable): 114 Gal, Oil Capacity (Each Engine): 12 quarts.
Wichita Dwight D Eisenhower Airport - KICT
Wichita, KS USA
